Can an HVAC Condensate Pump beat my Torture Test?

HVAC Shop Talk is a YouTube channel & podcast that celebrates the guys and girls in the skilled Trades – especially HVAC. #hvac #hvactraining #hvactech #hvactechnician #hvacpodcast

Join the HST Discord server –
Sign up for email notifications –

Beckett Corporation –
Yellow Jacket –
Company Cam –
EWC Controls –
TruTech Tools (Use my “SHOPTALK” promo code)

Contact me –

I want to do a little experiment with This condensate pump right here if you Take a closer look at it this is the Beckett Bk171ul 115 volt version it has a max Lift of 17 foot it pumps 112 gallons per Hour at one foot and this pump has a Three year warranty I'm Gonna Fill This Pump with water we're going to do a few Runs with this pump we're going to do One run without any obstructions or Anything like that this is 14 foot of 3 8 vinyl tubing The clamp here and the tape I have here And here to keep it so you guys can see It does not impact the tubing it isn't Squishing the tubing in any area so it Won't be a factor in this test I did Coil it up and that's just like it'll Appear most times in real life coiled up And run haphazardly as we all know from Being service tax and finding it on the Job site running like this I have my trusty duct tape covered Measuring cup I'm going to put the exact Same amount of water and each time I run The pump so this has four cups in it or Looks like 800 or a thousand milliliters Or one liter that is and I'm gonna start Here and see if this fills up the pump I'm gonna take it right close to the top Foreign Cup of that two liters should do it Now we're still about an inch inch and a

Half from the top Come on okay one and a half additional Cups and hopefully that is my best Calculation on what will not cause this To overflow as well Uh-oh I see some water coming from right Here So that is the maximum right there Looks like the maximum is going to be About nine cups or just shy of nine cups Yep So we'll probably do nine cups and I'll Probably make another mess So now that we have our nine cups in the Pump I'm gonna plug the pump in and We're gonna time how long it takes for The pump to push the entire cycle of Water through And we're going to compare that to a Couple other scenarios coming up [Music] So now I'm going to add a little monkey Wrench to the plant I'm going to put a Clamp on the line and we're going to see How much longer it takes to pump out the Same volume of water okay I refilled the Pump I'm going to put use one of my wood Clamps here to put a little bit of Pressure And we're going to close it off like say About A significant amount So There's not a whole lot left right there

I hope that that is I might have to back That off just slightly because I want There to be some flow All right let's see how we do there If you look at that it looks like it's Clamped Pretty tightly right there and it is Because the thick wall of the final two Being accounts for a lot of that spacing So let me make sure water actually comes Out the end of it but this will be if Someone has clamped it too tightly with Like one of those Electrical staples a Lot of guys like to put Electrical Staples to hold these in and if you go Too far with it you might end up Crushing this stuff at least to a Certain degree let's see how that Affects it we'll compare it with the Time we ran the first time [Music] What I've simulated here is a crimped Off vinyl tubing and this happens a lot Especially when it gets hot outside hot Up in the attic because this tube gets Very weak and pliable and has a tendency To Sag and crimp off So let's see what happens when we have Just one crimp that's relatively severe [Music] You can tell this one's making a Difference Foreign [Music]

A lot longer I can tell without seeing The measurement I want to thank Beckett for sending out This condensate pump right here and a Couple others that I can play with and Do experiments with to find out more About these pumps you can visit the Description of this video and there'll Be a link to Beckett us I was a little Surprised by how little the clamp Affected the piping whenever I just Clamped it down but whenever I kinked it Off it was pretty severe so next time we Go on a preventive maintenance or we're Installing a condensate pump make sure You take care that you don't put Yourself in a position where you'll be Coming back to fix a kink And remember more than anything else Always use best practices best practices Me doing the right thing all the time Doing All the time doing the right thing all The time Especially Friday at 4 30 [Music]
